100G Dual Fiber Port QSFP28 Ethernet OCP Mezzanine card with Intel E810-CAM2 Chip
Add to Cart
My Collection
Product features
The dual-port 100G Ethernet adapter provides QSFP28 module connectivity
Its design has excellent performance in the multi-processor system, and is applied to meet the needs of when virtualization and big data computing
When used with the Microsoft receiver extension or extenable I / O in Linux, the card effectively balances the network load between multiple central processing units (CPUs)
The scalable iscsi provides cost-effective SAN connection performance support
With an Intel ? PRO Smart installation, and for the Microsoft Device
New Intel ?PRO Set designed for Manager (Device Manager),
Thus simplifying the installation and management process, can be configured by simple clicks
Manage all of the Intel PRO network connections, and configure your connection requirements
Support hot plug-in
High-performance host interface designPCI Express 4.0(16GT/s)
Support for the RDMA function
Product description
GRT 100G Dual Fiber Port QSFP28 Ethernet OCP Mezzanine card is based on the Intel E810-CAM 2 Ethernet controller. With a fully integrated 100G Ethernet media access control (MAC) and an SFI interface.In addition to managing MAC and PHY Ethernet layer functions, the controller also manages PCI Express packet traffic for its transaction, link, and physical/logical layers.Using hardware acceleration, the controller unloads tasks from the host, such as TCP / UDP / IP checksum calculation and TCP segmentation.
The 100G Ethernet OCP Mezzanine card is the ideal solution for implementing multiple network segments, mission-critical high-performance network applications and environments in high-performance OCP servers.
Host interface：
? Support for OCP Mezzanine card 3.0 design specification
? Support for the connector installed on the mezzanine card
? PCI Express Gen 4.0 X16 channel
Dimensions:·
Open Compute Project Mezzanine card, Type 3
100G Ethernet adapter.
?-SRD: Fiber-optic 100G Ethernet rate
?-LRD: Fiber-optic 25G Ethernet Base-LX
LAN and virtualization features:
? VXLAN and NVGRE network virtualization unloading
? The unified network provides single lines for LAN and storage：NAS（SMB，NFS）和SAN（iSCSI，FCoE）
? Virtual bridging support - VEPA / 802.1Qbg，BPE / 802.1Qbh
? Virtualization supports 128 virtual ports per port
? Virtualization – eases virtual machine hypervisor I / O bottlenecks by providing flow separation for virtual machines (VM)
Specifications
Compatibility
All of GRT's products are open sourced, fully compatible with major brands' products and devices, such as Intel, Dell, Cisco, Finisar, Arista, HP, Mellanox, Juniper, HUAWEI, H3C, etc.
For other brands' devices, please specify when ordering so that we can write corresponding codes for your easy application.
Packing & Shipping
Packed in blister box and paper box, 1piece/box. Normal orders to be shipped within 2 working days upon receipt of payment.
We can ship by TNT, FedEx, EMS, UPS, DHL, or other named forwarders as per your request.
