PCI Express x16 25Gb 2 Port Fiber Optical NIC Network Card with GRT G810-2S chip
Add to Cart
My Collection
Product features
Dual-Port 25G Ethernet Adapter Provides SFP28 Optical Module Connectivity
Designed to provide excellent performance in multiprocessor systems, it is ideal for applications where virtualization and big data computing are required.
virtualization and big data computing requirements.
NIC temperature information can be read under the command system.
High-bandwidth, ultra-low-latency Ethernet network for high-speed transmission in cluster, LAN, and SAN networks to meet high-performance computing needs.
High-speed transmission of cluster networks, LAN networks, and SAN networks to meet the requirements of high-performance computing.
High performance host interface design PCI Express 4.0 (16GT/s)
Supports 12K jumbo frames
Compatible with various types of systems and equipment at home and abroad, autonomous and controllable.
Product description
Type:Wired
Data rate:25Gb/s
PCI Express Card Type:X16 Lane
Certification:FCC CE ROHS
Brand Name:GRT
Model Number:FF-2502E-V3.1
Rated power:22W
Ethernet controller: GRT G810-2S
Warrenty period:3 years
Application:Server, Servers, GAP, Firewall, storage device,etc.
Specification | |
Product Code name | FF-2502E-V3.1 |
Ethernet controller | GRT G810-2S |
Port | Dual port |
Connector | SFP28 |
Supported slot heights | Half-height and full-height |
Operating temperature | 0°C — 55°C |
Operating humidity | 0% — 90% No condensation |
LED indicator | The green light is the 25G rate indicator, the green blinking is the Link indicator, the indicator is not lit means that there is no network link. |
Giant frame | Support |
Rated power | 22W |
Speed and slot width | 16GT/S，x8Lane |
Physical Specifications | |
Length | 16.495cm |
Width | 6.891cm |
Large stopper | 12.43cm |
Small Baffle | 7.89cm |
PCIE Specification | X8 |
Operating System Support | |
Operating System | |
Linux* Stable Kernel version 2.6 | |
centos/redhat | |
Linux SLES 10 SP3 | |
Linux SLES 11 SP1 | |
UOS | |
Kylin V10 | |
NFS-CHINA | |
SUNWAY | |
deepin | |
Fetion | |
LINX SOFTWARE | |
ARM | |
Compatibility
All of GRT's products are open sourced, fully compatible with major brands' products and devices, such as Intel, Dell, Cisco, Finisar, Arista, HP, Mellanox, Juniper, HUAWEI, H3C, etc.
For other brands' devices, please specify when ordering so that we can write corresponding codes for your easy application.
Packing & Shipping
Packed in blister box and paper box, 1piece/box. Normal orders to be shipped within 2 working days upon receipt of payment.
We can ship by TNT, FedEx, EMS, UPS, DHL, or other named forwarders as per your request.
