100Gb/s Dual Optical port PCI-E X8 100G Single Mode Single Bypass Network Card with Intel E810-CAM2 Chip
Add to Cart
My Collection
Product features
Dual-port 100G rate, Ethernet adapter provides dual-fiber LC port connections
Innovative power management features and Energy Efficient Ethernet (EEE),
Intedrated direct memory access improves efficiency and reduces power consumption
Flexible I/O virtualization technology offers up to 256 virtual channels for port differentiation and Quality of Service (QoS)
High-performance host interface design PCI Express 4.0
Enables protection for backbone network communication
Product description
Type:Wired
Kind:Internal
Transmission Rate:100Gbps
Interface Type:PCI EXPRESS
Certification:FCC CE ROHS
Brand Name:GRT
Model Number:GH1102EBPLR-V3.0
Ethernet controller:E810-CAM 2
Bus type:PCI-Express X16
Hot pluggable:Yes
Warrenty period: 3 years
Application:Server, Servers, GAP, Firewall, storage device,etc.
Specifications
External network support：
Fiber 100G Ethernet 100G-LR：
1. 100G fiber ethernet port support 100G-LR（1310nm）
2. Two 100G 1310nm 10KM QSFP28 optical modules cannot be plugged and pulled，according customer requirements to adjust different single-modules in transmission distances；
Network card performance：
1. IPV4 and IPV6 support IP / TCP and IP / UDPreciving check and uninstallation；
2. Segmented UDP checksum uninstallation for packet restructuring;
3. CPU utilizatin-E810-CAM2 supports reduced CPU utilization，mainly by supporting receiver consolidation（RSC）；
4. Each port support 128 virtual machine device queues；
5. Support for direct cache access（DCA）；
6. Advanced memory architecture reduces latency befor passing TSO data package. TSOgroups can be interwoven with other groups on the going route；
7. Minimizes device I / O interruption using MSI and MSI-X;
8. Uninstall the TCP / IP / UDP checksum calculation and TCP segmentation；
9. High-volume on-chip receiving packet buffer（512 KB）；
10. Send data packet and buffer packet on the blockbuster（160 KB）；
11.Support VPD(important products data) function as defined in version 3.0 of the PCI specifiton；
12. Time synchronizaton-IEEE1588-exact time protocal（PTP）；
13. Besides EEDC function, the BCN(backward congeastin notifition) protocal is also supported.
Host interface：
PCI Express X16 channal；
Support PCI Express Base Specification 4.0（16GT / s）。
There are three modes of operation:
Normal operating mode.：
Bypass Working mode.：
Disconnect Working mode.：
Compatibility
All of GRT's products are open sourced, fully compatible with major brands' products and devices, such as Intel, Dell, Cisco, Finisar, Arista, HP, Mellanox, Juniper, HUAWEI, H3C, etc.
For other brands' devices, please specify when ordering so that we can write corresponding codes for your easy application.
Packing & Shipping
Packed in blister box and paper box, 1piece/box. Normal orders to be shipped within 2 working days upon receipt of payment.
We can ship by TNT, FedEx, EMS, UPS, DHL, or other named forwarders as per your request.
